Foundation Drilling Compressor
550 CFM / 16BAR
TEWATT 550CFM/16BAR Portable Air Compressors los nrog 5 xyoo lav TEWATT hom airend & roj kev lag luam Tier 3 emission standard Cummins cav, thiab thoob ntiaj teb tus qauv Donaldson, Parker, Fleetguard roj / cua lim, cov yam ntxwv siab heev uas ua rau nws sawv ntawm lwm cov cua compressors. hauv khw. Nws cov kev ua haujlwm siab, kev txav mus los, kev ua haujlwm ntev, kev siv roj, thiab kev saib xyuas yooj yim ua rau nws yog qhov kev xaiv zoo tshaj plaws rau cov kws tshaj lij uas xav tau cov cua compressor txhim khu kev qha thiab zoo. Features trailer-mounted configuration uas tso cai rau kom yooj yim txav ntawm qhov chaw ua hauj lwm. Thiab Finnish Akzo coated steel ua kom ruaj khov thiab ua haujlwm ntev, txawm tias ua haujlwm kub, txias txias, siab siab & siab plua plav hnyav ua haujlwm ib puag ncig. Haum rau dej zoo drilling, mining, chaw txua txiag zeb, kev tsim kho, sandblasting, moj tej tawg qhov drilling, shotcreting, anchoring & DTH drilling thiab lwm yam.
Nta & Cov txiaj ntsig:
Tewatt Screw Air-end Super rotor, qis ceev (5 xyoo / 10000 teev warranty)
Cummins Cav Tier 2 emission standard, 3000 teev / 2 xyoo warranty ntev.
Tewatt Intelligent Controller.
Kev nyab xeeb thiab txhim khu kev qha cua lim & nkag qhov system.
Cov zis hluav taws xob siab: Cov compressors no yog tsim los xa cov cua compressed siab, ua rau lawv muaj peev xwm drilling los ntawm cov pob zeb nyuaj.
Durability: Cov compressors yog ua los ntawm cov ntaub ntawv zoo uas tiv taus hnav thiab tsim kua muag, ua kom lawv lub neej ntev thiab kev ntseeg tau.
Mobility: Cov compressors feem ntau yog ntsia rau ntawm cov tsheb thauj khoom lossis tsheb thauj khoom, ua rau lawv yooj yim txav ntawm ib qho mus rau lwm qhov.
Kev ua kom txias tau zoo: Cov compressors tau nruab nrog lub tshuab ua kom txias kom tsis txhob muaj cua sov, tso cai rau lawv ua haujlwm rau lub sijhawm ntev.
Kev tsim khoom ntau ntxiv: Lub zog tso zis siab ntawm cov compressors ua kom nrawm dua thiab ua haujlwm zoo dua, ua rau muaj kev tsim khoom ntau ntxiv.
Kev txuag nqi: Lub durability ntawm compressors txhais tau hais tias lawv yuav tsum tsis tshua muaj txij nkawm thiab hloov, ua rau cov nqi txuag rau lub tuam txhab mining.
Versatility: Kev txav mus los ntawm cov compressors tso cai rau lawv siv ntau yam kev ua haujlwm tsuas, ua rau lawv muaj ntau yam cuab yeej.
Kev ua haujlwm nyab xeeb: Lub tshuab ua kom txias ua kom muaj kev nyab xeeb ntawm cov compressors, txo qhov kev pheej hmoo ntawm kev sib tsoo lossis kev puas tsuaj uas tuaj yeem ua rau cov neeg ua haujlwm lossis cov khoom puas.
Daim ntawv pov thawj
CE, SGS ISO9001 / ISO 14001, Daim ntawv pov thawj suab nrov
Technical Specifications:
| Qauv | TWT550D-16T |
| Compressor theem | Theem ib leeg |
| Kev xa tawm huab cua dawb (CFM / M3/ min) | 550 cfm (16 m3/ min) |
| Ua haujlwm siab (psig / bar) | 232 hli (16bar) |
| Ntsia Hlau Roj Volume-(L) | 50L |
| Diesel Cav | CUMMINS |
| Cav Qauv | 6BTA5 9-C210-30 |
| Rated zog (HP / KW) | 210HP/154KW TSI |
| Rated Ceev/Idle (rpm) | 2200/1350 |
| Lub tog raj kheej | 6 |
| Qhov siab (mm) | 102 hli |
| Mob stroke (mm) | 120 hli |
| Kev tshem tawm (L) | 5.9L |
| Emission Class | EU theem II / TIER 2 |
| Roj teeb voltage (V) | 24V |
| Roj Tank Peev Xwm (L) | 120L |
| Connector Loj * Qty | G3/4" *1, G 2"* 1 |
| Log Loj * Qty | 7.00-16*2 |
| Qhov hnyav (Kgs) | 2500 KG |
| Qhov Loj (mm) | 4230mm * 2100mm * 2040mm |
| Suab nrov {dB(A)} | 80 ± 5 dB (A) |
| Ua haujlwm kub (degree) | -15 degree ~ +50 degree (cov xwm txheej tshwj xeeb tuaj yeem hloov kho) |
Nco tseg: Cov lus qhia tshwj xeeb tuaj yeem hloov pauv yam tsis muaj ntawv ceeb toom ntxiv.
Yuav ua li cas xaiv tus nqi-zoo thiab txhim khu kev qha portable cua compressor rau mining?
Xaiv lub xov tooj cua compressor rau kev ua haujlwm tsuas tuaj yeem ua haujlwm tsis txaus ntseeg, vim muaj ntau yam yuav tsum xav txog. Nov yog qee cov lus qhia los pab koj xaiv txoj cai mobile air compressor rau koj daim ntawv thov mining:
Peev Xwm: Txiav txim siab huab cua xav tau ntawm koj qhov kev lag luam mining thiab xaiv lub xov tooj cua compressor uas ua tau raws li lossis tshaj qhov xav tau. Lub compressor nrog lub peev xwm ntau dua yuav muaj peev xwm ua tau raws li qhov xav tau ntawm huab cua loj dua thiab txo qis sijhawm.
Mobility: Xaiv lub xov tooj cua compressor uas yooj yim rau kev thauj mus los thiab ua haujlwm ntawm qhov chaw ntxhib. Nrhiav cov compressors uas tau nruab rau ntawm cov tsheb thauj khoom lossis cov tsheb thauj khoom, thiab cov log loj, hnyav hnyav lossis cov lem kom ruaj khov thiab traction.
Lub hwj chim qhov chaw: Xav txog lub hwj chim qhov chaw rau koj compressor. Diesel-powered compressors yog zoo tagnrho rau tej thaj chaw deb los yog off-grid mining lag luam, thaum hluav taws xob compressors yog zoo tshaj plaws haum rau mining hauj lwm nrog ib tug txhim khu kev qha hwj chim qhov chaw.
Kev Kho: Xaiv lub compressor uas yooj yim rau kev tswj hwm thiab kev pabcuam, nrog rau cov lim siv tau, roj, thiab cov cua cais. Nrhiav cov compressors nrog onboard diagnostic systems uas tuaj yeem ceeb toom koj txog tej yam teeb meem ua ntej lawv loj.
Huab cua tej yam kev mob: Xav txog tej yam kev nyab xeeb ntawm koj cov mining. Yog tias koj ua haujlwm nyob rau hauv qhov kub thiab txias, xaiv lub compressor nrog lub zog txias txias uas tuaj yeem tiv thaiv overheating.
Qib suab nrov: Xaiv lub compressor uas muaj suab nrov tsawg los txo cov suab nrov thiab tiv thaiv cov neeg ua haujlwm hnov lus.
Zoo: Xaiv lub xov tooj cua compressor los ntawm lub chaw tsim khoom muaj koob npe nrog cov ntaub ntawv pov thawj ntawm kev tsim cov cuab yeej zoo. Nrhiav cov compressors nrog cov khoom siv ruaj khov thiab cov khoom siv, thiab tau dhau los ua kev sim nruj.
Los ntawm kev txiav txim siab txog cov xwm txheej no, koj tuaj yeem xaiv lub tshuab cua compressor zoo rau koj daim ntawv thov mining, txhim kho kev ua tau zoo, tsim tau, thiab kev nyab xeeb ntawm koj qhov kev lag luam mining.
